20km Mini secure wireless data link for miniature and micro-drones

The FIP-2420 is a fully integrated, high powered microwave transmitter, based on aircraft industry standards for ruggedness, size, and weight. Highly efficient H.264 Encoding is a standard feature. It features AES Bcrypt decryption capabilities that make it ideal for applications ranging from public security monitoring to covert surveillance.

Specification:

• Transmission distance: (outdoor) with the 5db standard omni-directional TX antenna,transmission distance over 20 km
• Band frequency: 2.402GHz - 2.482GHz
• Modulation mode: TDD-COFDM
• Video input: Mini ETH *1
• RS232 port*1
• TTL Port*1
• Compatible input video format HD all format: up to 1920x1080P @ 60fps
• Output format: 352x288@30fps, 720x576@30fps, 1280x720p@30/60fps, 1920x1080p @ 30fps, 1920x1080p @ 60fps
• Compression: High definition television broadcasting
• Channel: 80 channels (manually frequency hopping, anti-jamming)
• Support Auto Polit System: Pixhawk
• Support RC: Futaba T14SG
• Software Support system: Window 7 8 10
• Data interface: TTL transmission interface
• RF Power Adjustable: 23dbm-30dbm adjustable by software
• Communication encryption: AES 256bit encryption
• Temperature: -40℃-85℃

Items Included in the Box:

• Transmitter*1
• Recevier*1
• 5dbi TX Omni Antenna *2
• 10dbi RX Omni Antenna*1
• 7dbi RX Omni Antenna*1
• RS232 Cable*1
• TTL Cable*4
• T33 Cable for Pixhawk*1
• Power Cable*4
• LAN Cable*4
• Antenna Cable*4

About us:

IFLY Bi-Directional Data Links are wireless communication units specifically designed for long range links for various types of unmanned aerial and ground vehicles. It support 5km/10km/20-30km/30-50km/70-120km range. It mostly application is for mapping, emergency, detect and Sea Rescue.

By employing leading wireless technologies, the IFLY family of products delivers long-range communication that supports Bi-directional Data and enables real-time full HD Video Streaming.

IFLY stands out from other UAV communication systems in that it combines control, telemetry and payload into one RF channel and in a compact and lightweight solution.

With AES encryption mechanism, built-in flexibility to optimize to customer needs and robust link that operates in long-ranges and overcomes dead spots, IFLY UAV data link provides safe link for drone communication in government, army and commercial applications.

Why IFLY?

IFLY provides H.264/H.265 ,CODEC RTL IP Cores,
CODEC FPGA Boards, and CODEC FPGA Modules for hardware video systems.

IFLY maintains technique co-operation relationship with some world well-known enterprises, such as Sony ,Panasonnic and Huawei.
IFLY UAV radio links provides comprehensive progress in the video transmission application technology, develop high-standard product solutions and perfect customer service system.

1. Bi-directional and configurable software defined radio (SDR) data link

2. 5km-120km Line-of-Sight (LOS) range

3. ISM Frequency 1.2G/1.3G.1.4G/2.3G/2.4G/2.5Ghz for your option

4. Encrypted & Secured

5. Control, monitoring, telemetry and real-time Full HD rvideo

6. Compatible with Pixhawk fly controller

7. Compact & Lightweight Solution

8. Support Video Input HDMI and IP

9. Latency 15-30ms
